New York City Approved LED Exit & Incandescent Emergency Combo
Two fully adjustable 12W, glare-free lamp heads with field installable 3rd emergency lighting head included. K/Os provided on sides of unit to relocate lamp heads. High performance smooth metal reflector and glass lens for optimal light distribution. Ultra bright, energy efficient, long life Red LED. New York City compliant 8” EXIT letters.
- Mounting hardware provided for back surface wall mount.
- Top and side K/Os provided for conduit feed applications.
- Five year warranty on all electronics and housing. Battery prorated for two years.
- Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
Color / Finish
- Black
- Gray
- White
Lamp Source
- LED
Materials
- Metal
- Steel
- Thermoplastic
Mounting
- Surface
- Wall
Ratings & Compliance
- NFPA 101
Voltage
- 12 V
- 120 V
- 277 V
- Durable, powder-coated 20-gauge steel construction in Injection-molded, engineering grade, high-impact, thermoplastic heads.
- Field removable steel knockout chevron directional indicators on exit face.
- Dual 120/277 voltage.
- Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
- LVD (low voltage disconnect) prevents battery from deep discharge.
- 6V maintenance-free, rechargeable sealed lead acid battery.
- Internal solid-state transfer switch automatically connects the internal battery to LED board and lamp heads for minimum 90-minute emergency illumination.
- Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
