MFPMFP
Floor Proximity
A low profile and powerful LED recessed fixture for Mounting up to 4 ft from floor level. Dual function operation in either emergency or normal mode, powered from the Signtex central battery system at 24VDC.
- Operates with Central Battery System including low voltage normal lighting operation.
- Dual function operation for night or security lighting as well as emergency lighting.
- Very low power consumption compared to any fluorescent or incandescent lighting systems.
- Over 50,000 hour lamp life in normal use.
- Manufactured and tested to UL Standard 924 and NFPALife Safety Code 101.
Color / Finish
- Black
- White
Lamp Source
- Fluorescent
- LED
Listings
- UL
Materials
- Acrylic
- Aluminum
- Polycarbonate
- Steel
Mounting
- Bracket
- Cove
- Recessed
Ratings & Compliance
- Buy America
- Exterior
- Wet
Voltage
- 120 V
- 120-277 V
- 24 V
- 277 V
- Faceplate from solid machined aluminum, available with brushed finish or a variety of satin enamel paint colors.
- Steel housing with bracket mount locations and multiple knockouts for wiring connection.
- Composite outdoor rated gasket seal for wet location operations.
- UV stabilized polycarbonate or acrylic diffuser window 1/8” thick delivers wide beam output.
- Modular faceplate and lamp housing removes to allow easy access for service.
- Lamps are connected in parallel. If one lamp fails, one or more lamps will continue in operation.
- 10 watts total system power. -40 o C Standard minimum operating.
- LED color temperature standard 5300K, available color temperatures 3000K.
- An advanced LED driver module is incorporated in the fixture, allowing dual operation from either a battery or normally on power source.
- Lamps are connected in parallel-series strings, as required to meet requirements of NEC and Life Safety Codes.
- Lighting continues even after failure of one lamp or circuit.
Resources
- Faceplate from solid machined aluminum, available with brushed finish or a variety of satin enamel paint colors.
- Steel housing with bracket mount locations and multiple knockouts for wiring connection.
- Composite outdoor rated gasket seal for wet location operations.
- UV stabilized polycarbonate or acrylic diffuser window 1/8” thick delivers wide beam output.
- Modular faceplate and lamp housing removes to allow easy access for service.
- Lamps are connected in parallel. If one lamp fails, one or more lamps will continue in operation.
- 10 watts total system power. -40 o C Standard minimum operating.
- LED color temperature standard 5300K, available color temperatures 3000K.
- An advanced LED driver module is incorporated in the fixture, allowing dual operation from either a battery or normally on power source.
- Lamps are connected in parallel-series strings, as required to meet requirements of NEC and Life Safety Codes.
- Lighting continues even after failure of one lamp or circuit.
- Operates with Central Battery System including low voltage normal lighting operation.
- Dual function operation for night or security lighting as well as emergency lighting.
- Very low power consumption compared to any fluorescent or incandescent lighting systems.
- Over 50,000 hour lamp life in normal use.
- Manufactured and tested to UL Standard 924 and NFPALife Safety Code 101.
